Oki MC560n - MFP Overview; Front View

MFP Overview > 14
MFP O VERVIEW
F RONT VIEW
MFP front.eps
1
4
5
6
7
9
10
11
12
2
3
2
8
1. Output stacker, face
down. Standard printed
copy delivery point. Holds
up to 250 sheets at 20 lb.
(80g/m²).
2. Multi purpose tray release
buttons (press).
3. Operator Panel with LCD
display. Status LEDs and
operator buttons.
4. Front Cover release (lift).
5. Paper tray.
Standard blank paper
tray. Holds up to 300
sheets of 20 lb. (80g/m²)
paper.
6. Multi purpose feeder (shown closed). Used
for feeding heavier paper stocks,
envelopes and other special media. Also
for manual feeding of single sheets when
required.
7. Automatic Document Feeder (ADF) Unit.
8. LCD Display.
9. ADF Paper Tray.
10. ADF Paper Support.
11. Document Cover.
12. Control Panel.
