Installing upgrades > 144
2. Pull open the access panel on the side of the machine.
Side cover open.eps
3. Locate the clip (1) on the top of the disk unit into the slot
(2) in the printer.
4. Plug the end of the connecting cable (3) into the disk unit
connector (4) in the printer.
5. Tighten the two thumbscrews (5).
HDD install1.eps
2
1
3
5
4
5
