- 146 -
9. Troubleshooting
3
Press the button (A) and open the output tray (d) completely.
4
Remove the four image drums from the machine and place the image drums
on a flat surface.
While removing consumables, be careful not to hit them to the LED head.
5
Cover the removed image drums with paper so that the image drums are not
exposed to light.
6
Remove the jammed paper slowly by pulling the edge of paper.
Burns may result.
The fuser unit is extremely hot. Do not touch it.
To Next Page
