- 63 -

3. Basic Operations

Inside of the machine

Symbol Name

a LED head

b Fuser unit

c Toner cartridge / Image drum (Y: yellow)

d Toner cartridge / Image drum (M: magenta)

e Toner cartridge / Image drum (C: cyan)

f Toner cartridge / Image drum (K: black)
