Oki MC563 MFP User Manual

- 35 -
2. Setting Up
Connecting a LAN Cable/USB Cable
When using the machine in a wired network connection or connecting to a computer via a
USB cable, connect the cable in the following steps.
• Connecting a LAN Cable
• Connecting a USB Cable
A LAN cable (category 5e or higher, twist pair, straight) is not supplied.
1
Prepare a LAN cable (category 5e or higher, twist pair, straight) and hub.
2
Check that the machine and computer are turned off.
3
Open the interface cover on the back side of the machine pressing the center
part of it.
Connecting a LAN Cable

Oki MC563 MFP Specifications

General

Print Technology	LED
Print Resolution	1200 x 1200 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax	Yes
Monthly Duty Cycle	Up to 60, 000 pages
Functions	Print, Copy, Scan, Fax
Duplex Printing	Yes
Print Speed	Up to 30 ppm
Scanner Type	Flatbed, ADF
Copy Speed	Up to 30 cpm
Connectivity	USB, Ethernet
Paper Capacity	250 sheets
