ML1120/ML1190 User’s Guide - Paper handling > 41
settiNg the PaPer thickNess lever
There are 6 lever positions, the first 5 for printing purposes and the sixth
to facilitate ribbon replacement.
Set the Paper Thickness lever for different paper types as follows:
PAPER TYPE LEVER POSITION
1 2 3 4 5 - 6
Cut sheet paper See below
52 - 80 gsm X
81 - 127 gsm X
Envelope X
Carbon paper or Pressure- sensitive
paper (40 gsm)
See below
2 part X
3 part X
4 part X
5 part X
Set the Paper Thickness lever for overall paper thickness as follows:
OVERALL PAPER THICKNESS LEVER POSITION
0.06 - 0.10 mm 1
0.11 - 0.18 mm 2
0.19 - 0.25 mm 3
0.26 - 0.32 mm 4
0.33 - 0.39 mm 5
0.40 - 0.46 mm 6
