Loading paper > 17
7. Adjust the right tractor to centre the paper holes on the pins, and push back the lock
lever.
8. Lower the paper separator and place the wire guide (1) on the pull-up roller
assembly (2).
9. Press FF/LOAD. The paper feeds into the printer.
L
OADING
SINGLE
SHEETS
(T
OP
FEED
)
Use the single-sheet path for letter head stationery, memos, and individual envelopes. It
is recommended for printing graphs and charts because it provides the most accurate
control of the paper.
1. Make sure the printer is on and deselected (SEL light off).
2. Place the paper lever in the position marked “TOP”.
NOTE
The standard setting for the Top of Form (where the printing begins) is 2.54cm
down from the top of the page. To change the setting, “Setting the top of form
(TOF)” on page 19.
NOTE
If you have continuous-form paper in the path, press the PARK button to
remove it before loading single sheets.
1
2
