Paper handling > 24
10. Close the Top Cover.
11. Open and remove the front cover (1).
12. Holding by the tabs, guide the tractor into the side frames and push it downwards to
lock it in place.
Loading continuous form (front)
1. Ensure that the printer is turned ON.
2. Ensure that the Paper Type Lever is set to Continuous form “FRONT” .
3. Open the Top Cover, adjust the Paper Thickness Lever to suit the paper
. See “Setting
the Paper Thickness lever” on page 33.
4. Lift the locking lever of the left Pin Tractor and slide the Pin Tractor as required to
adjust the paper position then press the locking lever back down to lock the Pin
Tractor in the desired position.
5. Lift the locking lever of the right pin tractor and slide the Pin Tractor to the required
position to accommodate the width of the continuous forms to be used. Move the
paper guide midway between the left and right Pin Tractors.
NOTE
If front cover is already open and the front cut sheet paper tray has been
installed, gently lift the tray from the bottom and remove it, and then remove
the front cover.
FRONT
To Next Page
