Operating instructions > 53
Set-up
cont.
Print DEL Code
(Displayed only for
ML Emulation)
Change the setting to
Yes to print the DEL code
(decimal 27) as a solid
box.
No
Yes
-
SI Select Pitch (10
CPI) (Displayed
only for IBM
emulation)
Select how to handle an
SI command received in
10 CPI mode.
17.1 CPI
15 CPI
SI Select Pitch (12
CPI) (Displayed
only for IBM
emulation)
Select how to handle an
SI command received in
12 CPI mode.
12 CPI
20 CPI
Time Out Print Select valid or invalid. Invalid
Valid
Auto Select Determines whether or
not the printer will
automatically be
selected after you load
in paper. Select No if you
want to set the Top of
Form position.
Yes
No
Host Interface Selects which interface
the printer uses to
receive printing
commands.
Auto Interface
Parallel
USB
Optional
I/F Time Out Sets the length of time
before the interface
switches to idle status
when no printing
commands have been
received.
15 sec
30 sec
45 sec
1 min
2 min
3 min
4 min
5 min
ESC SI Pitch
(Displayed only for
IBM emulation)
Sets the character pitch
used when the ESC SI
command is received.
17.1 CPI
20 CPI
Select Language
Set
Changing the language
set replaces certain
standard symbols with
special characters used
in foreign languages.
Combined
Code Page Only
Print Style Select the printer impact
mode.
Normal
High Speed
Quiet
High Copy
Select Quiet Mode Select Quiet print mode. Mode 1
Mode 2
Select High Copy
Mode
Select High Copy print
mode.
Mode 1
Mode 2
Mode 3
Mode 4
Reverse Feed
Control
Set reverse feed control. TOF Stop
TOF Over
GROUP ITEM FUNCTION SETS
ML5720/ML5721 ML5790/ML5791
