Descriptionoftheheatingcontrollermodule

17.2Settingtheaddressattheburnercontroller

Adjustthetheburnercontrollerusingtheaddressswitch.Ifoperatingasacascadesystemsettheswitchaccordingly.

Basesetting=0

Attheoperatingwithcascadesystemsyouassigntoeveryboilerwith0beginningthesuitablenumber.

Propertydamage

Adjusttheorderusingtheaddressswitchthisisonly

possiblewhenthesystemispowereddown.

E1389EN2.0
