Pellematicsettings
80
CapacitiveSensorRA
Active
Activatethecapacitivesensorontheburner.
0=inactive
CapacitiveSensorZW
Active
Activatethecapacitivesensoronthehopper.
0=inactive,1=active
Doyouhaveaburnerplatecleaningsystem,itrunsparallelwiththeexternalde-
ashingsystem.
Note
Replacewith:Iftheboilerhashadnoburnerdemandin5daysthede-ashing
systemwillautomaticallyactivateonFridayat12:00for3/5minutes.This
preventsthesettlingofashintheauger.
Beforeeachignitionthede-ashingsystemand/ortheburnerplatecleaningsystem
areactivefor20seconds.
27.10BoilerControlledPump
BoilerControlledPumpisinthePellematicmenu.
BoilerControlledPumphasfollowingmenuitems
•OnTemp
•DependsOnRequire
•SpeedController
•SwitchOffHyst
•RunOnTime
•ControlRange
Note
TheoutputBoilercontrolledPumpislimited
to2.5A.
TheadditionalmenuitemsBoilerControlledPumparefortheÖkoFENServicetechnician.Theyarepresent
afterenteringthecode:
OnTempWhenreachingtheOnTemptheoutputUWisactivatedorswitchedontheBoiler
ControlledPump.TheOnTempistheboilertemperatureminimum.
DependsOnRequireWhenreachingtheOnTempandanexistenceofDependsOnRequiretheoutput
UWisactivated.(Theburnerrunontimeisconsidered)
SpeedControllerTheSpeedControllerallows(aftertheirrelease-OnTempandDependsOn
Require)theBoilerControlledPumpinthecyclingmode.
SwitchOffHystTheSwitchOffHystisthehysteresisfortheboilertemperatureminimum.It
preventstheclocking(ONOFFONOFF)oftheBoilerControlledPump.
RunOnTimeTheRunontimeishowlongtheUWcontinuestorunaftertheendofburner
demand.–inminutes
ControlRangeIstheControlRangeofoutputUWatcyclingmode.Thespeedcontrollerstartsat
theboilertemperatureminimumwithaspeedof30%andincreasestotheboiler
temperatureminimum+ControlRangeupto100%speed.
