Descriptionoftheheatingcontrollermodule

17.5Assemblyanddisassemblyoftheheatingcontrollerboard

Itispossibletotakeofftheheatingcontrollerboardfromthecontrollercasingwithoutdisconnectingtheinputsand

outputs.

1.Makesuretheheatingsystemispowereddown.

Electrostaticdischargedamage

Beforestartingwork,touchagroundedobjecttoavoid

damagetotheinsulationboardbyelectrostaticcharging.

2.Openthecoverplateoftheheatingcontroller.

Seepreviouschapter17.4Assemblyordisassemblyofthepowersupply,page49

3.Pullalltheplugsinfromthecircuitboard.Leavetheplugswiththewiringinthecasing.

4.Disassembleofthepowersupply(optional)

Seepreviouschapter17.4Assemblyordisassemblyofthepowersupply,page49

5.Disassemblethecircuitboardfromtheheatingcontroller.

6.Theinstallationofanewcircuitboardshouldbeinreverseorder.

OperatingmanualPelletronicTouch

E1389EN2.0
