the range.
- Blinking light: Controller in maintenance mode (test, calibration).
The Failure reset is automatic once the failure disappears.
Green start/stop indicator for the detectors/modules of the zone.
- Off: All the detectors of the zone are stopped.
- Fixed light: At least one of the detectors of the zone is working.
- Blinking: The information details of one of the detectors/modules of the zone are
actually displayed on the LCD screen.
Flash and siren (D and E)
Siren (D)
Located in the upper portion of the box, the siren is optionally available solely
in the wall-mounted version. It is always discontinuous and is configured via
the COM 43 application.
Flash (E)
Located in the upper portion of the box, the flash is optionally available solely
in the wall-mounted version. It is configured via the COM 43 application.
Status indicators (F and G)
These two indicators reflect the status of the MX 43.
Green general start/stop indicator denoting the power supply status
- Fixed: Correct power supply.
- Off: No power supply.
- Blinking: Power supply problem (absence of power in the sector or problems in the
internal battery pack.
Failure/maintenance orange indicator
- Off: No failure detected.
- Fixed light: Presence of some failure (controller, detector, communication, memory).
The alarm goes off automatically once the failure is cleared.
- Blinking light: MX 43 in maintenance mode (test, calibration).
Alarm reset Key (H)
Pressing this key has the effect of releasing the internal buzzer and the
alarms that it enables. This key has the same function as the remote release
key that may be connected; see paragraph on the Remote Acknowledgement
connector on page 37.
Zone Identification (J and K)
Pull the tab to write in the zone labels.
