d-Color MF 3300/3800 3-3
3.1 Checking the connection method
3
3 Manually Installing the Printer Driver (for Windows)
3.1 Checking the connection method
In Windows Vista/7/8/Server 2008/Server 2008 R2/Server 2012
The installation method for the printer driver differs depending on the method used to connect this machine
to the computer. When this machine is connected to the network, there are several printing protocols. The
installation method for the printer driver also differs depending on the protocol.
Installation method Connection method
Connection method in
which setup is possible
using Add Printer Wiz-
ard
LPR A network connection using the LPR (Line Printer Re-
mote) print service. It uses a TCP/IP protocol and the
LPR printing port.
• For the installation procedure, refer to page 3-5.
Port 9100 A network connection using the PORT9100 print ser-
vice. It uses a TCP/IP protocol and the RAW printing
port.
• For the installation procedure, refer to page 3-5.
IPP/IPPS A network connection using the IPP (Internet Printing
Protocol) print service. Printing can be carried out via
the Internet using the HTTP (HyperText Transfer Proto-
col) of the TCP/IP protocol.
IPPS is an IPP for SSL encrypted communication.
• For the installation procedure, refer to page 3-11.
Web service print It is a connection corresponding to Web service function
of Windows Vista and later operating systems and capa-
ble of automatically detecting the printer on the network.
• For the installation procedure, refer to page 3-14.
USB A connection using a USB port.
Connection method in
which plug and play-
based setup is possible
USB A connection using a USB port.
• For the installation procedure, refer to page 3-15.
