Olivetti d-Copia 3003MF - Page 171

2MH/2MJ/2MK/2ML
1-5-34
8. Remove the rear cover.
Figure 1-5-51
9. Remove two screws and then remove
the fuser unit.
Figure 1-5-52
Rear cover
Fuser unit
Screw
Screw
Service Manual Y113860-1
