2MH/2MJ/2MK/2ML
1-5-38
6. Remove five screws and then remove
the control box.
Figure 1-5-56
7. Remove seven screws and two
grounding terminals and then remove
the control PWB.
Figure 1-5-57
Controll box
Screw
Screw
Screw
Screw
Screw
Controll PWB
Screw
Screw
Screw
Screw
Screw
Screw
Grounding
terminal
Screw
Grounding
terminal
