8. Remove five screws and then remove
the control PWB.
9. Check or replace the control PWB and
refit all the removed parts.
To replace the control PWB, remove the
EEPROM (U17) from the old control
PWB and mount it to the new control
PWB.
Figure 1-5-58
EEPROM
U17
Control PWB
CF guide
Control PWB
