Olivetti DP-670 - Periodic Maintenance Procedures

3K5-1
2-4-2
Periodic maintenance procedures
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Test copy
and test print
Perform at the maxi-
mum copy size
Clean Every service.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Original feed
section
DP forwarding pulley Replace 150K Replace (Clean with alcohol
when user call occurs).
P. 1 -5- 2
DP feed pulley Replace 150K Replace (Clean with alcohol
when user call occurs).
P. 1 -5- 2
DP separation pad Replace 150K Replace (Clean with alcohol
when user call occurs).
P. 1 -5- 5
Friction plate Clean Every service. Clean with alcohol.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Original con-
veying sec-
tion
Conveying roller Clean Every service Clean with alcohol or a dry
cloth.
Conveying pulley Check or
clean
150K Clean with alcohol or a dry
cloth.
Scanning guide Clean Every service Clean with alcohol or a dry
cloth.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Original
switchback
section
Switchback roller Clean Every service Clean with alcohol or a dry
cloth.
Switchback pulley Check or
clean
150K Clean with alcohol or a dry
cloth.
Eject roller Clean Every service Clean with alcohol or a dry
cloth.
Eject r pulley Check or
clean
150K Clean with alcohol or a dry
cloth.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Other Original holder mat Clean 150K Clean with alcohol or a dry
cloth.
Service Manual Y108671-9
