(4) Solenoids
Figure 2-2-4 Solenoids
1. Switchback feedshift solenoid (SBFSSOL).. Operates the switchback feedshift guide.
2. Switchback pressure solenoid (SBPSOL).... Operates the switchback pulley.
2
1
Machine front Machine inside Machine rear
