Olivetti DP-670 - Motors

3K5
2-2-3
(3) Motors
Figure 2-2-3 Motors
1. Original feed motor (OFM) ........................... Drives the original feed section.
2. Original conveying motor (OCM) ................. Drives the original conveying section.
3. Original switchback motor (OSBM).............. Drives the original switchback section.
4. DP cooling fan motor (DPCFM) ................... Cools the drive section.
1
3
2
4
Machine front Machine inside Machine rear
Y108671-9 Service Manual
