Olivetti DP-670 - Removing the Tapes and the Spacer

3K5
1-2-3
(2) Removing the tapes and the spacer
Procedure
1. Remove two tapes.
Figure 1-2-2
2. Open the document processor top cover.
3. Raise the DP feed pulley unit.
4. Open the spacer.
5. Raise the original table.
6. Remove the spacer.
7. Remove the plastic bag.
Figure 1-2-3
Tape
Tape
Document processor top cover
Original table
Spacer
Plastic bag
DP feed pulley unit
Y108671-9 Service Manual
