Olivetti DP-670 - Contents of Maintenance Mode Items (Monochrome)

3K5
1-3-19
(3) Contents of maintenance mode items
Maintenance
item No.
Description
U019
Displaying the ROM version
Description
Displays the part number of the ROM fitted to each PWB.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the * or # keys.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Display Description
MAIN Main PWB ROM IC
MAIN BOOT Main PWB booting
ENGINE Engine PWB ROM IC
ENGINE BOOT Engine PWB booting
LANGUAGE Standard language ROM IC
OPTION LANGUAGE Optional language ROM IC
DICTIONARY -
PRINTER Optional printer board ROM IC
DP DP main PWB ROM IC
OPTION CASSETTE Optional paper feeder main PWB ROM IC
INNER DF Optional built-in finisher main PWB ROM IC
SIMPLE DF MAIN Optional document finisher main PWB ROM IC
ENGINE POWER Engine power CPU
Y108671-9 Service Manual
