Olivetti DP-670 - Maintenance Mode Item List (Monochrome)

3K5-1
1-3-18
(2) Maintenance mode item list
Section
Item
No.
Content of maintenance item
Initial
setting*
General U019 Displaying the ROM version -
Optical U068 Adjusting the scanning position for originals from the DP 0/0
*1
U070 Adjusting the DP magnification 0/0
*1
U071 Adjusting the DP scanning timing 0/0/0/0
*1
U072 Adjusting the DP center line 0/0/0
*1
U074 Adjusting the DP input light luminosity 0
*1
U087 Setting DP reading position modification operation 35
*1
Operation
panel and
support
equipment
U203 Checking DP operation -
U243 Checking the operation of the DP motors -
U244 Checking the DP switches -
Mode setting U326 Setting the black line cleaning indication ON/8
*1,*2
processing
U404 Adjusting margins for scanning an original from the DP 3.0/2.5/3.0/4.0
*1
U411 Adjusting the scanner automatically -
Other U905 Checking counts by optional devices -
U942 Setting of deflection for feeding from DP 0/0
*1
*Initial setting for executing U020, *1: The item initialized for executing U020, *2: The item initialized for executing U021
Service Manual Y108671-9
