3K5
1-3-27
U244
Checking the DP switches
Description
Displays the status of the respective switches in the DP.
Purpose
To check if respective switches in the DP operate correctly.
Method
1. Press the start key.
2. Turn the respective switches on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U326
Setting the black line cleaning indication
Description
Sets whether to display the cleaning guidance when detecting the black line.
Purpose
Displays the cleaning guidance in order to make the call for service with the black line decrease by the rubbish
on the platen when scanning from the DP.
Setting
1. Press the start key.
2. Select ON or OFF.
Initial setting: ON
3. Press the start key. The setting is set.
Setting the count value
1. Enter a count using the cursor up/down keys.
Setting range: 0 to 999
Initial setting: 8
When setting is 0, the black line cleaning indication is displayed only if the black line is detected.
2. Press the start key. The count is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Switches
DP SET SW Original set switch (OSSW)
DP PSD SW Original size length switch (OSLSW)
DP REV SW Original switchback switch (OSBSW)
CCD TIMING SW DP timing switch (DPTSW)
DP COVER SW DP interlock switch (DPILSW)
DP OPEN SW DP open/close switch (DPOCSW)
Display Description
ON Displays the cleaning guidance
OFF Not to display the cleaning guidance
COUNT Setting counts of the cleaning guidance indication
