Olympus BXC-CBB - Page 29

(2) BXC-CBE1
1.
Connect BXC-CBB and BXC-CBE1 with BXC-LCBL1M.
(3) BXC-RLI
1.
Use BXC-LCBL3M or BXC-LCBL6M to connect BXC-RLI and BXC-CBB.
(4) AC adapter
1.
Connect the control box BXC-CBB and the AC adapter (provided with BXC-CBB).
2.
Insert the power cord connector (A) into the connector (B) of the AC adapter.
25
3. Setup procedures 3.12 Connecting cables
