4.12 Inspection of the high intensity mode
CLV-190 INSTRUCTION MANUAL
Ch.4
1 Press the brightness mode button on the
control panel and confirm that the “MANU”
indicator lights up.
Figure 4.19
2 Press the brightness buttons on the control
panel to set the brightness level to 0.
Figure 4.20
3 Press the intensity mode button on the control
panel: the normal mode is changed to the high
intensity mode.
Figure 4.21
4 Confirm that the high intensity mode indicator lights up and that the light emitted from
the endoscope’s distal end increases compared to the normal mode.
5 Press the intensity mode button to switch to the normal intensity mode. (See
Figure 4.21)
Brightness mode button
Brightness mode indicators
Brightness buttons
Brightness indicator
High intensity mode indicator
Intensity mode button
