6.2 Removal of the lamp
85
CLV-190 INSTRUCTION MANUAL
Ch.6
When replacing the examination lamp, use a clean, lint-free cloth to wipe off
residual heat compound from the heat sink. If the heat compound is not wiped off
completely, the lamp’s heat efficiency will be impaired and the examination lamp life
will be shortened significantly.
Washers are attached to bolts. Retain all three of them carefully because they will
be used again to clamp the new examination lamp.
Figure 6.6
12 Remove the clamp of heat sink (A) and pull out the examination lamp. (See
Figure 6.5)
13 Using a clean, lint-free cloth, wipe off any residual heat compound from the heat sink.
