90
6.3 Insertion of the lamp
CLV-190 INSTRUCTION MANUAL
Ch.6
12 Turn the knobs of the lamp cover and close the
lamp cover securely.
Figure 6.15
For safety, the light source is designed so that it cannot be turned ON if the lamp
cover is not attached securely.
13 Proceed with Section 6.4, “Lamp usage indicator reset” below.
Lamp cover
Knobs
Lamp chamber
