SPECIFICATIONS
Item Specifications
1. Optical system Infinity Correction optical system
2. Illumination
Built-in 0.5 W LED illumination system.
Rated voltage: 5-6 V 0.5 A
(AC adapter: 100-240 V 50/60 Hz 0.4A)
Power consumption: 1.7 W
3. Focusing mechanism Stage height adjustment mechanism.
Fine adjustment scale: 2.5 μm per graduation
Fine adjustment stroke: 0.3 mm per turn
Total stroke: 20 mm.
Pre-focusing knob provided, coarse adjustment knob tension adjustable.
4. Revolving nosepiece Quadruple positions fixed (Front oriented)
5. Binocular observation tube
Field number 20
Tube tilting angle 30°
Interpupillary distance
adjustment range
48 to 75 mm
6. Stage
Size 120 x 132 mm (with mechanical stage)
Movement range 76 (X-axis) x 30 (Y-axis) mm
Specimen holder Holds a single specimen.
7. Condenser
Type Abbe condenser
N. A . 1.25 (when immersed in oil)
Aperture iris diaphragm Built in
8. Dimensions & weight 154(W) x 392(H) x 238(D) mm, approx. 6 kg
9. Operating environment
· Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 5° to 40°C (41° to 104° F)
· Maximum relative humidity: 80% for temperatures up to 31°C (88°F),
decreasing linearly through 70% at 34°C
(93°F), 60% at 37°C (99°F), to 50% relative
humidity at 40°C (104°F).
· Supply voltage fluctuations; Not to exceed ±10% of the normal voltage.
· Pollution degree: 2 (in accordance with IEC60664-1)
· Installation/Overvoltage category: II (in accordance with IEC60664-1)
10. Transport and Storage environ-
ment
· –25 to +65 °C
· 0 to 90 %RH
