4
CX22LED
STANDARD COMPONENT UNITS
}After opening the package, make sure that the correct component units for the selected set are included.
The 100X objective and immersion oil are provided only with the CX22LEDRFS1 set.
The objectives have been screwed in tightly to prevent them from being loosened during transportation.
To remove an objective, turn it counterclockwise while holding it with a rubber sheet, etc., so that your
fingers don’t slip.
Eyepieces
(Fixed at 10X)
Stage
Condenser
Microscope frame
· 4X, 10X, 40X, 100X
(CX22LEDRFS1)
· 4X, 10X, 40X
(CX22LEDRFS2)
Immersion oil
· Provided with a set including
the 100X objective.
Optional Accessories
· Filter Holder
CH2-FH
· Reflection Mirror
CH20-MM
· Eyepieces
WHC15X
WHC15X-H
· Darkfield Ring
CH2-DS
AC adapter
Power cord
Binocular observation
tube
Objectives
Revolving nosepiece
· Cord Hanger
CX22LED-CH
CAUTION
To Next Page
