Olympus E-3 User Manual

11
EN
Basic guide
Preparing the battery
3
2
1
BLM-1 Lithium ion
battery
AC wall outlet
BCM-2 Lithium ion
charger
AC cable
Remove the protection cap
from the battery.
Align the battery with the arrow.
Battery lock
It is recommended to set aside a backup battery for prolonged shooting in case the battery in use
drains.
1 Charging the battery
3 Close the battery compartment cover and slide the battery
compartment lock in the direction of
E
Press the battery lock to unlock
the battery. Turn the camera
upside-down to remove the
battery.
Battery compartment
lock
Battery compartment cover
Direction
indicating mark
W
Unloading the
battery
2 Loading the battery
Charging indicator
Red light: Charging in progress
Green light: Charging completed
(Charging time: Approx. 5 hours)
W
Preparations for shooting

Olympus E-3 Specifications

General

Megapixel	10.1 MP
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	4/3 \
Supported aspect ratios	4:3
Maximum image resolution	3648 x 2736 pixels
Digital zoom	0 x
Optical zoom	5 x
Interface	USB
Power source	BLM-1
Video capability	No
Camera shutter speed	1/8000 - 60 s
Display diagonal	2.5 \
Magnification	1.15 x
Product color	Black
Image editing	resizing, rotating
Photo effects	black&white, Sepia
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Tungsten
Camera playback	Slide show
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Compatible memory cards	xd
Light metering	centre-weighted, spot
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE

Weight and Dimensions

Depth	74.5 mm
Width	142.5 mm
Height	116.5 mm
Weight	810 g
