Information
12
ZUIKO DIGITAL lens specifications
Names of parts
1
Hood mount section
2
Filter mount thread
3
Zoom ring
4
Focus ring
5
Mount index
6
Electrical contacts
7
Front cap
8
Rear cap
9
Lens hood
•
Use the hood when shooting a backlit subject.
Main Specifications
Attaching the hood
Storing the hood
Items 12 – 60 mm 50 – 200 mm
Mount FOUR THIRDS mount
Focal distance 12 – 60 mm 50 – 200 mm
Max. aperture f2.8 – 4.0 f2.8 – 3.5
Image angle 84° – 20° 24° – 6.2°
Lens configuration
10 groups,
14 lenses
15 groups,
16 lenses
Multilayer film coating
(partially single layered)
Iris control f2.8 – 22 f2.8 – 22
Shooting range 0.25 m –
)
1.2 m –
)
Focus adjustment AF / MF switching
Weight (excluding hood and cap) 575 g 995 g
Dimensions (Max. diameter x overall length) Ø
79.5 x 98.5 mm Ø
86.5 x 157 mm
Lens hood mount Bayonet
Filter mount thread diameter 72 mm 67 mm
