Olympus E-3 User Manual

2
EN
4
Camera
Hot shoe
g P. 8 1, 84
F (Exposure
compensation) button
g P. 47
LIGHT button
g P. 14
Self-timer / Remote control lamp /
Remote control receiver
g P. 60, 61
Mirror
Lens release button
g P. 1 2
Lens attachment mark
g P. 12
Mount
(Attach the lens after removing the body cap
from the camera to prevent dust and dirt from
entering the camera body.)
Shutter button
g P. 16, 34
Lens lock pin
Sub dial (
k )
g P. 26 – 30
Built-in flash
g P. 78
# (Flash) button g P. 7 7
w (Flash intensity control) button
g P. 7 9
Remote cable connector
g P. 131
Strap eyelet
g P. 1 0
AF button g P. 5 2
G (Metering) button g P. 4 6
COPY / < (Copy / Print) button
g P. 92, 111
MODE button g P. 40 – 44
< / Y / j (Remote control / Self-timer /
Sequential shooting) button
g P. 59 – 61
White balance sensor
g P. 68, 107
ISO button
g P. 5 0
WB (White balance) button
g P. 68
Control panel
g P. 6 , 26
External flash connector
g P. 8 4
# UP (Flash pop-up)
button
g P. 78
USB connector
g P. 11 2 , 116
VIDEO OUT jack ( VIDEO OUT )
g P. 90
DC -IN jack
g P. 133
Connector cover
Preview button
g P. 45

Olympus E-3 Specifications

General

Megapixel	10.1 MP
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	4/3 \
Supported aspect ratios	4:3
Maximum image resolution	3648 x 2736 pixels
Digital zoom	0 x
Optical zoom	5 x
Interface	USB
Power source	BLM-1
Video capability	No
Camera shutter speed	1/8000 - 60 s
Display diagonal	2.5 \
Magnification	1.15 x
Product color	Black
Image editing	resizing, rotating
Photo effects	black&white, Sepia
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Tungsten
Camera playback	Slide show
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Compatible memory cards	xd
Light metering	centre-weighted, spot
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE

Weight and Dimensions

Depth	74.5 mm
Width	142.5 mm
Height	116.5 mm
Weight	810 g
