Information
12
Can be used with the optional EX-25 extension tube under the following conditions.
The focus adjustment when EX-25 is used will be MF.
Storage Precautions
•
Clean the lens after use. Remove dust and dirt on the surface of the lens with a blower brush or
brush. Use commercially available lens cleaning paper to remove the dirt on the lens. Do not use
organic solvents.
•
Always cap the lens and store it when it is not used.
•
Do not store in an area with insect repellent.
x
Notes on Shooting
•
Edges of pictures may be cut off if more than one filter is used or if a thick filter is used.
In the
P
mode, the camera is programmed such that the aperture value and shutter speed are
automatically selected according to the subject’s brightness as shown below. The program line
diagram varies with the type of lens mounted.
Lens, focal distance Shooting range
Magnification
( ): Calculated based on 35 mm film
camera
12 – 60 mm
12 mm
Shooting is not possible since subjects cannot be brought into focus at this
focal length.
60 mm 21.0 cm – 25.5 cm 0.43 – 0.58x (0.86 – 1.16x)
50 – 200 mm
Can be shot in the whole
zoom range
0.12 – 0.49x (0.24 – 0.98x)
Program line diagram (
P
mode)
When using the
14 – 54 mm f2.8 – 3.5 zoom
lens
(focal length: 14 mm, ISO100)
Program shift
Aperture value
Shutter speed
k
j
