Olympus E-P2 User Manual

5
EN
Preparations for shooting
Basic guide
Attaching a lens to the camera
1
2
2
1
Body cap
3
3
4
1
2
Lens cap
Alignment mark
(Red)
Lens attachment mark
(Red)
2
1
Lens release button
1 Remove the body cap from the camera and the
rear cap from the lens
2 Attach a lens to the camera
• Do not touch internal portions of
the camera.
• Make sure the camera is turned off.
• Do not press the lens release
button.
3 Remove the lens cap
(
3, 4)
Removing the lens from the camera
While pressing the lens release button (1),
rotate the lens in the direction of the arrow
(2).
g“Interchangeable lenses” (P. 129)
• Align the lens attachment mark (red)
on the camera with the alignment
mark (red) on the lens, then insert
the lens into the camera’s body (1).
• Rotate the lens in the direction
indicated by the arrow until you hear
it click (2).
Rear cap
Lens release
button
s0026_e_00_0_unified.book Page 5 Tuesday, September 29, 2009 10:30 AM

Olympus E-P2 Specifications

General

Sensor Type	Live MOS
Sensor Size	17.3 x 13.0 mm (Four Thirds)
Effective Pixels	12.3 megapixels
ISO Sensitivity	ISO 100-6400
Image Processor	TruePic V
Autofocus System	Contrast-detect AF
Screen Size	3.0 inches
Screen Resolution	230, 000 dots
Video Recording	720p HD
Storage Media	SD/SDHC card
Weight	335 g (body only)
Lens Mount	Micro Four Thirds
Shutter Speed	60 - 1/4000 sec
Continuous Shooting	3 fps
Battery Type	BLS-1 Lithium-Ion battery
Dimensions	120.5 x 70 x 35 mm
Camera Type	Mirrorless
Viewfinder	Optional (VF-2)
