Inspection Before Use
3
3.1 Setup of Connected Equipment
32
This document, “INSTRUCTIONS (ADVANCED),”
explains equipment other than described in
“INSTRUCTIONS (BASIC).”
Refer to the instruction manuals of the connected
equipment, which must be set up as required for use with
this instrument.
Be sure to refer to “Chapter 3 Inspection Before Use” in
“INSTRUCTIONS (BASIC),” which has a description
of non setting-related inspections for the connected
equipment and this instrument.
3.1 Setup of Connected Equipment
Chapter 3 Inspection Before Use
Table 3.1
Connected
equipment
Instruction Manual
references
Setup Item Setup Note
CV-160 “6.9 Image recording and
playback”
“Using a video printer”
“Operation from the
keyboard”
“#PER PAGE”
switch on the
keyboard.
From “1,” “2,” “4”,
“N”
Select the number of multi-picture images.
Select any one except “8” and “16.”
“PRINT QTY.”
switch on the
keyboard.
From “1,” “2,” “3”,
“N”
Set the number of print quantity.
Print quantity is set up from a menu when it is
set as “N,” according to “Printer settings” in
“5.3 System setup.” Select any setting.
“5.3 System setup”
“Printer settings”
“Type” “OEP3” Select the printer type. Be sure to set “Type”
to “OEP3” when using this instrument.
“Qty. “N”” “4” – “ 9” Select the print quantity when the “Print
quantity indicator” on the keyboard is set to
“N.” Select any setting, as required.
“Caption” Max. 40 characters. Input the characters to be printed in the margin
of the print sheet.
“5.4 User presets”
“Setting [User Preset – Edit
Data] menu”
“Setting endoscope remote
switch functions”
“Scope remote
switches”
“Switch 1”
“Switch 2”
“Switch 3”
“Switch 4”
“Printer”
“P.Back”
Select the functions to be controlled from the
scope switches on the videoscope or OES
video converter. Select any setting, as
required.
To Next Page
