3.12 Communication interfaces (USB, Ethernet, expansion
ports)
3.12.1 Interfaces
ETH1 and ETH2
Connector RJ-45
Link speed 10/100/1000 Mbit/s
Power over Ethernet (PoE) IEEE 802.3af (15.4 W max.)
IEEE 802.3at (30 W max.)
Cable Cat 5e STP (Shielded Twisted Pair) or better
PC
Connector USB type B
Speed USB 2.0 high speed (480 Mbit/s)
Power consumption Self-powered
Cable USB 2.0 high speed or better
USB
Connector USB type A
Speed USB 2.0 high speed (480 Mbit/s)
Output current 500 mA max.
Cable USB 2.0 high speed or better
EXPANSION PORTS
Connector TE Mini I/O
Protocol Proprietary (non-Ethernet compliant)
Power over Ethernet (PoE) IEEE 802.3af (15.4 W max.)
IEEE 802.3at (30 W max.)
Cable Cat 5e STP (Shielded Twisted Pair)
3.12.2 Power over Ethernet (PoE) power sharing
All Ethernet and expansion ports share the same power supply and are limited by a common power
budget of 75 W. The two Ethernet ports have priority over the expansion ports.
