RX Quick Start Guide 3
RX Quick Start Guide
1 SPECIFICATIONS
1.1 Upon receipt
Please perform the following task after receiving the drive:
• Inspect the driver for damage. If the drive appear damage upon receipt, contact your supplier.
• Verify the receipt of the correct model by checking the information on the nameplate. If you have received the wrong model contact your
supplier.
• Refer to the User’s Manual for detailed information about the product and functions.
Basic specifications and EMC filter
Vol t ag e
Type HD (150% overload for 60s) ND (120% overload for 60s)
EMC filter
3G3RX- Max Motor (KW) Rated current (A) Max Motor (KW) Rated current (A)
3 x 200 V
A2004 0.4
3.0
0.75 3.7
AX-FIR2018-RE
A2007 0.75
5.0
1.5 6.3
A2015 1.5
7.5
2.2 9.4
A2022 2.2
10.5
3.7 12.0
A2037 3.7
16.5
5.5 19.6
A2055 5.5
24.0
7.5 30.0
AX-FIR2053-RE
A2075 7.5
32.0
11 44.0
A2110 11
46.0
15 58.0
A2150 15
64.0
18.5 73.0
AX-FIR2110-RE
A2185 18.5
76.0
22 85.0
A2220 22
95.0
30 113.0
A2300 30
121.0
37 140.0
AX-FIR2145-RE
A2370 37
145.0
45 169.0
AX-FIR3250-RE
A2450 45
182.0
55 210.0
A2550 55
220.0
75 270.0
AX-FIR3320-RE
3 x 400 V
A4004 0.4 1.5 0.75 1.9
AX-FIR3010-RE
A4007 0.75 2.5 1.5 3.1
A4015 1.5 3.8 2.2 4.8
A4022 2.2 5.3 4.0 6.7
A4040 4.0 9.0 5.5 11.1
A4055 5.5 14.0 7.5 16.0
AX-FIR3030-RE
A4075 7.5 19.0 11 22.0
A4110 11 25.0 15 29.0
A4150 15 32.0 18.5 37.0
AX-FIR3053-RE
A4185 18.5 38.0 22 43.0
A4220 22 48.0 30 57.0
A4300 30 58.0 37 70.0
AX-FIR3064-RE
A4370 37 75.0 45 85.0
AX-FIR3100-RE
A4450 45 91.0 55 105.0
AX-FIR3130-RE
A4550 55 112.0 75 135.0
B4750 75 149.0 90 160.0
AX-FIR3250-RE
B4900 90 176.0 110 195.0
B411K 110 217.0 132 230.0
AX-FIR3320-RE
B413K 132 260.0 160 290.0
