RX Quick Start Guide
6 RX Quick Start Guide
2 INSTALLATION
2.1 Wiring sizes and protection
2.2 Terminal symbols, screw size and tightening torque
Type 3G3RX-
Main Circuit Option Control Circuit Relay
R(L1),S(L2),T(L3),U
(T1),V(T2),W(T3)
Ro, To
Ground
(symbol)
PD(+1),P(+),
N(-),RB
AM,AMI,H,O,O2,OI,L,FM, FW, 8, 7,
6, 5, 4, 3, 2, 1, CM1,PLC,P24,CM2,
15,14,13,12,11,TH
AL0,AL1,AL2
A2004 to A2037
A4004 to A4040
M4
M4
M4 M4
M3 M3
A2055,A2075
A4055,A4075
M5 M5 M5
A2110,A4110 M6 M5 M6
A2150,A2185
A4150 to A4220
M6 M6 M6
A2220 M8 M6 M8
A2300 M8 M6 M8
A4300 M6 M6 M6
A2370 M8 M8 M8
A4370 M8 M8 M8
A2450 M8 M8 M8
A4450,A4550 M8 M8 M8
A2550, B4750 to B413K M10 M8* M10
Screw Size M3 M4 M5 M6 M8 M10
Torque 0.7 N·m (max. 0.8) 1.2 N·m (max. 1.4) 2.4 N·m (max. 4.0) 4.5 N·m (max. 4.9) 8.1 N·m (max. 8.8) 20.0 N·m (max. 22.0)
200V 400V
Motor Output
(kW)
Inverter Model
3G3RX-
Power Terminal
Wiring Size Range (AWG)
Torque (N·m)
Motor Output
(kW)
Inverter Model
3G3RX-
Power Terminal
Wiring Size Range (AWG)
To rq u e
(N·m)
0.4 A2004 14 (Stranded only) 1.8 0.4 A4004 14 (Stranded only) 1.8
0.75 A2007 0.75 A4007
1.5 A2015 1.5 A4015
2.2 A2022 2.2 A4022
3.7 A2037 10 (Stranded only) 4.0 A4040
5.5 A2055 8 4.0 5.5 A4055 12 4.0
7.5 A2075 6 7.5 A4075 10
11 A2110 6 or 4 11 A4110 8
15 A2150 2 4.9 15 A4150 6 4.9
18.5 A2185 1 18.5 A4185
22 A2220 1 or 1/0 8.8 22 A4220 6 or 4
30 A2300 2/0 or Parallel of 1/0 30 A4300 3
37 A2370 4/0 (Prepared wire only) or
Parallel of 1/0
20.0 37 A4370 1 20.0
45 A2450 45 A4450 1
55 A2550 350 kcmil (Prepared wire
only) or Parallel of 2/0
(Prepared wire only)
19.6 55 A4550 2/0
75 B4750 Parallel of 1/0
90 B4900
110 B411K Parallel of 3/0 35.0
132 B413K
