4 Maintenance and inspection
4-5 Replacing the fan
BU5002R/BU3002R/BU3002RH
112
3.
Fully insert the connector of the new fan until a “clicking” sound is heard. ()
Insert the fan into the main unit ().
Fan


4.
Fix the fan on the back of the UPS unit with 4 screws using a Phillips screwdriver.
Attach it with four screws.
