2 Installation and connection
2-2 Installation
BU5002R/BU3002R/BU3002RH
37
2
5.
Place the UPS on the support angles, push it in all the way to the back (), and
securely fix the ear brackets onto the server rack using the 4 provided EIA/JIS
rack fixing screws (M5). ()



6.
After fixing, install the battery.
See “4-4 Replacing the battery” for the installation procedure.
