Instruction Support and Operand Restrictions Section 2-6
EXPLICIT SET
ATT RI BUT E
ESATR 722 S: 1st word of send
message
WORD Yes (not
fixed)
C: 1st control word WORD Yes (3)
EXPLICIT WORD
READ
ECHRD 723 S: 1st source word
in remote CPU Unit
UINT Specify
the desti-
nation
address
when
using AT
settings.
D: 1st destination
word in local CPU
Unit
UINT Yes (2)
C: 1st control word WORD Yes (5)
EXPLICIT WORD
WRITE
ECHWR 724 S: 1st source word
in local CPU Unit
UINT Yes (not
fixed)
D: 1st destination
word in remote
CPU Unit
UINT Specify
the desti-
nation
address
when
using AT
settings.
C: 1st control word WORD Yes (5)
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT
setting or
array
variable
required
(Required
word data
size
shown in
parenthe-
ses.)
ESATR
S
C
ECHRD
S
D
C
ECHWR
S
D
C
