Advanced Function Setting Level Section 5-6
When the “multi-SP uses” parameter is set to “ON”, you can select set points
0 to 3 by operating the keys on the front panel of the controller.
When the option event input unit E53-AZB is mounted on the E5AZ/E5EZ, this
parameter can be used when the “number of multi-SP uses” parameter is set
to “0” and “multi-SP uses” is set to ON.
on: You can select set points 0 to 3.
off: You cannot select set points 0 to 3.
• Default: OFF
■ Related parameters
“Multi-SP” (operation level)
“Number of Multi-SP uses” (advanced function setting level)
• This parameter specifies the change rate during SP ramp operation. Set
the maximum permissible change width per unit of time (minute) as the
“SP ramp set value”. However, note that when the “SP ramp set value” is
set to “OFF”, the SP ramp function is disabled.
• During temperature input, the decimal point position of the SP ramp set
value is dependent on the currently selected sensor, and during analog
input it is dependent on scaling.
■ Related parameters
“Input type” “Scaling upper limit” “Scaling lower limit” “Decimal point” “ST” (ini-
tial setting level)
Multi-SP uses
The “number of multi-SP uses”
parameter must be set to “0” on mod-
els on which the option event input
unit E53-AZB is not mounted.
mspu
Function
Setting
See
SP ramp set value
ST (self-tuning) must be set to
“OFF”.
Parameter
Setting Range Unit Default
SP ramp set value OFF, 1 to 9999 EU Ooff
Function
Setting
See
