Setting Output Specifications Section 3-5
In this example, let’s monitor the “input type”, “temperature unit”, “direct/
reverse operation” and “control period (OUT1)” parameters.
“input type” = “5”: K thermocouple
“temperature unit” = “c”:
°C
“direct/reverse operation” = “or-r”: reverse operation
“control period (OUT1)” = “20 (secs)”
1,2,3... 1. Press the key for at least three seconds to move from the “operation
level” to the “initial setting level”.
2. The input type is displayed. When you are setting the input type for the first
time, “5”: K thermocouple is set. To select a different sensor, press the
or key.
3. Select the “temperature unit” parameter by pressing the key. Default
is “c”:
°C. To select “f”: °F, press the key.
4. Select the “control period (OUT1) parameter by pressing the key.
Default is “20”.
5. Select the “direct/reverse operation” parameter by pressing the key.
Default is “or-r”: reverse operation. To select “or-d”: direct operation,
press the key.
6. To return to the “operation level”, press the key for at least one sec-
ond.
Operation Procedure
Operation level
30
0
C
Input type
Initial setting level
in-t
5
Temperature unit
d-u
c
Direct/reverse
operation
PV/SP
Operation level
Control period
(OUT1)
cp
20
30
0
C
oreV
OOor-r
C
