When you click the Don't Install, the process proceeds without installing drivers. If you mistak-
enly click it, turn off the Sensor Controller to install the driver again.
8 After the following message dialog is displayed, remove the USB memory stick or SD card and
then click OK.
Precautions for Correct Use
Never remove the USB memory stick or SD card before the above message dialog appears. As
the update process is not successfully completed, the measurement application software may
not be correctly launched.
When you click OK, the Sensor Controller automatically restarts.
Be sure to check that the Sensor Controller starts and operates normally.
Precautions for Correct Use
Make sure to click OK. If not, files and settings in progress are left, which may cause the
Sensor Controller malfunction.
Troubleshooting
Case Possible cause Measures
The version-up
tool does not start.
The file for the version-up tool stored in
external storage may be corrupted.
Format the external storage storing the version-
up tool, and then save the version-up tool again
to run it.
A message dialog
of You can not
start a firmware
upgrade tool. is
displayed and the
version-up tool
does not start.
The software data of the version up-
grade tool may not be compatible with
the version upgrade in the state stored
in other than directly under the external
storage.
Store the VerupXP.exe file so that it is located di-
rectly below the USB memory stick or SD card,
and then perform the version upgrade.
3 Basic Operations
3 - 42
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
