Item
Set value
[Factory default]
Description
Enable timing
• [ENABLE start]
• STEP start
Set the timing for starting the pulse count.
• ENABLE start: Counts the pulses input during the meas-
urement trigger receipt period.
• STEP start: The pulses are not counted even during the
measurement trigger receipt period until the STEP signal
is input.
Pulse reset timing
• [Every trigger
pulse]
• Every rotation
(Pulse Z)
Every STEP
Set the timing for resetting. When ENABLE start is specified
for Enable timing, you can select Every trigger pulse or
Every rotation (Pulse Z).
When STEP start is specified for Enable timing, you can se-
lect Every trigger pulse or Every STEP.
When Every rotation is set, multiple pulses can be set for
phase A.
Phase A trigger [0] to 65535 Set how many pulses it takes to produce a trigger.
Support backlash-
ing (using phase
B)
• Checked
• [Unchecked]
Set whether the rotation direction is detected.
Trigger in back-
lashing
• Checked
• [Unchecked]
Set to produce a trigger during reverse rotation.
Phase Z
Enable timing
• [ENABLE start]
• STEP start
Set the timing for starting the pulse count.
• ENABLE start: Counts the pulses input during the meas-
urement trigger receipt period.
• STEP start: The pulses are not counted even during the
measurement trigger receipt period until the STEP signal
is input.
Pulse reset timing
• [Every trigger
pulse]
Set the timing for resetting the pulse count of phase Z.
Every trigger pulse: Reset the pulse count of phase Z each
time the Sensor Controller outputs a trigger.
Phase Z trigger [1] to 1023 Set how many pulses it takes to produce a trigger.
4 Setting the Controller
4 - 51
FH/FHV Series Vision System User’s Manual (Z365-E1)
4-12 Setting Encoder Trigger [Encoder Trigger Setting]
