Icon Function Description
Variable assign-
ment list
Displays the Variable assignment list dialog.
Filter
Sets a display filter for the Scene variable list. The setting for
the filter is performed with the Filter setting dialog
displayed.
Refresh Refresh the variable list.
(c) Menu bar:
This is a list of functions provided in the System variable tab in the Edit flow screen. Clicking the
menu item displays available functions with a shortcut menu.
• File:
Icon Function Description
(None) Close Closes the screen and exits the TDM editor.
• Editing:
Icon Function Description
Registered image Opens the Registered image dialog to manage the Regis-
tered images.
You can save images used for model registration and refer-
ence registration as registration images and can reference
them later and use them for reregistration and adjustment of
reference positions.
Refer to 6-6 Managing Images used for Model Registration
and Reference [Registered Image Manager] on page 6 - 38.
• Display:
Icon Function Description
(Npne) Large buttons Enlarges the size of the icons/buttons displayed on the Edit
flow button area.
• Edit flow:
This is available only when the Edit flow tab is selected in the Edit item tab area.
• Scene variable:
Scene variable: This is available only when the Scene variable tab is selected in the Edit item
tab area.
• System variable:
System variable: This is available only when the System variable tab is selected in the Edit
item tab area.
The items displayed when clicking this are same as buttons in the Variable button area.
(d) System variable list:
Display a list of System variables being used. The values of the System variables can be edited.
(e) Remaining variable definitions:
Display the remaining available (bytes) to be used for the variable definition.
