2
Select a scene on the scene list to copy and click Copy.
3 On the scene list, select a scene to paste and click Paste.
A Confirmation of overwrite dialog will be displayed.
4
Click OK.
The copied scene is overwritten to the selected scene.
Deleting a Scene
1 Select Scene tab on the TDM editor.
A list of scenes is displayed. The current scene has a check mark.
5 Creating Measurement Scenes
5 - 41
FH/FHV Series Vision System User’s Manual (Z365-E1)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-3 Editing Scenes [TDM Editor]
