Right-click Menu 1
The following shortcut menu is displayed when right-clicking on window parts.
Item Description
Delete the window Deletes a selected window part.
Send to Back Moves a selected window part to the rearmost face.
Set transparent color Displays the Set transparent color dialog.
Copy of window parts Copies a window part if the window part can be placed more than one. If the
window part cannot be copied, a message dialog box appears.
Layout menu Same as Layout dropdown menu list.
l
Right-click Menu 2
The following shortcut menu is displayed when right-clicking on a place where no window parts is
placed.
8 Setting Windows
8 - 18
FH/FHV Series Vision System User’s Manual (Z365-E1)
