Item
Setting value
[Factory default]
Description
Pre-Process - Specifies the subroutine name (including *) to execute before dis-
playing the Setup window using up to 32 characters.
Post-Process - Specifies the subroutine name (including *) to execute after clos-
ing the Setup window using up to 32 characters.
Status - Set the status of Window Part.
Enable - Specifies the variable to store the custom dialog display window
status from the variable assignment window.
However, only the scene variable or system variable can be speci-
fied.
Refer to Assigning variables on page 5 - 60.
The variable value is 0. : Set the Custom dialog to disabled state.
The variable value is Other than 0. : Set the Custom dialog to en-
abled state.
Selected - Specifies the variable to store the custom dialog display window
status from the variable assignment window.
However, only the scene variable or system variable can be speci-
fied.
Refer to Assigning variables on page 5 - 60.
The variable value is 0. : Set the Custom dialog to normal state.
The variable value is other than 0. : Set the Custom dialog to se-
lection state.
Front/Back - Specifies the variable to store the custom dialog display window
status from the variable assignment window.
However, only the scene variable or system variable can be speci-
fied.
Refer to Assigning variables on page 5 - 60.
When the variable value is positive. : Move window to the front.
When the variable value is negative. : Move window to the back.
When the variable value is 0. : Do not move the window.
Control - Sets when changing the status for the custom dialog display but-
ton using a macro.
Control ID 0 to 999 The ID used to identify the operation target if using the macro Rai-
seOptionEvent relationship to carry out operations.
Text & Font Setting - Display the setting contents for Text Setting, Font Setting, and
Color Setting.
Text Setting - Sets character data to display.
Data Type
• [Direct input]
• Variable
Sets text data to display on the button.
• Direct:
Directly input to the Text Data.
• Variable:
Specify a system variable or a scene variable of character
string type that defines a character string to display.
Text Data 0 to 128 characters Specifies text data to display on the button.
Data Type
(Selected)
• [Direct]
• Variable
Sets text data to display at the button selection.
• Direct:
Directly input to the Text Data.
• Variable:
Specify a system variable or a scene variable of character
string type that defines a character string to display.
Text Data
(Selected)
0 to 128 characters Specifies text data to display at the button selection.
8 Setting Windows
8 - 51
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-3 Arranging Windows [Layout Functions]
8
8-3-19 Custom Dialog Display Button Window (MDI_ExecuteBtn.dll)
